语义分割数据集转为目标分割

// Same level next // Same level previous // Child // Parent let mut hierarchy = opencv::core::Vector::opencv::core::Vec4i::new(); imgproc::find_contours_with_hierarchy_def( &mat, &mut contours, &mut hierarchy, imgproc::RETR_CCOMP, imgproc::CHAIN_APPROX_SIMPLE, ) .unwrap();

在之后就是最关键的处理有洞多边形的部分，核心原理是先找到洞边框与外边框最近的点，这两个点之后会用一条线连接起来，让外边框的线从这个链接点进入内部洞的边框，旋转一圈后再链接回外边框，
由于边框的点是有序的，在处理过程中需要将内边框点的顺序翻转，这样才能和外边框连在一起；此外还要注意边框点的数量，少于3个的话无法形成个真正的多边形，因而需要舍弃掉

<details>
<summary>边框处理与多边形生成</summary>


```rust
let mut combined_contours: Vec<Vec<(i32, i32)>> = Vec::new();

// Now go through all the hierarchy and combine contours
let mut current_index: i32 = 0;
while current_index != -1 && !contours.is_empty() {
    let current_contour = contours.get(current_index as usize).unwrap();
    let current_hierarchy = hierarchy.get(current_index as usize).unwrap();

    let mut parent_points = Vec::<(i32, i32)>::new();
    current_contour.iter().for_each(|point| {
        parent_points.push((point.x, point.y));
    });
    if current_hierarchy.get(2).unwrap() != &-1 {
        // Contain child, go through holes
        let mut child_contour_index = *current_hierarchy.get(2).unwrap();
        loop {
            let child_contour =
                contours.get(child_contour_index as usize).unwrap();
            let child_hierarchy =
                hierarchy.get(child_contour_index as usize).unwrap();

            let mut child_points = Vec::<(i32, i32)>::new();
            child_contour.iter().for_each(|point| {
                child_points.push((point.x, point.y));
            });
            if child_points.len() > 10 {
                // Find the nearest point between child_points and contour_points
                let mut min_distance = f64::MAX;
                let mut child_index = 0;
                let mut parent_index = 0;
                for (i, parent_point) in parent_points.iter().enumerate() {
                    for (j, child_point) in child_points.iter().enumerate() {
                        let distance = f64::from(
                            (parent_point.0 - child_point.0).pow(2)
                                + (parent_point.1 - child_point.1).pow(2),
                        )
                        .sqrt();
                        if distance < min_distance {
                            min_distance = distance;
                            child_index = j;
                            parent_index = i;
                        }
                    }
                }

                // Combine two contours
                let mut new_points = Vec::<(i32, i32)>::new();
                new_points.extend(parent_points.iter().take(parent_index + 1));
                new_points.extend(child_points.iter().skip(child_index));
                new_points.extend(child_points.iter().take(child_index + 1));
                new_points.extend(parent_points.iter().skip(parent_index));
                parent_points = new_points;
            }
            child_contour_index = *child_hierarchy.first().unwrap();
            if child_contour_index == -1 {
                break;
            }
        }
    }
    // No more child
    if parent_points.len() > 10 {
        // Can't form valid polygon
        combined_contours.push(parent_points);
    }

    current_index = *current_hierarchy.first().unwrap();
}

额外备注

在此之外，需要注意的是YOLO本身的数据加载与处理部分写的巨烂无比，充斥着各种magic number和bug，在此说一个和上文相关的就是在其加载polygon数据的时候会通过线性插值将其强制扩充到1000个点， 但是由于物体可能靠着边缘，所以可能会出现直角边缘被线性插值变为斜角的情况，因而可以把resample_segments改为下面的

def resample_segment(s, n):
    # s is a segment with shape (m, 2), where m is the number of points in the segment
    # n is the desired number of points in the resampled segment
    resampled_s = np.empty((0, 2), dtype=s.dtype)
    diff = np.diff(s, axis=0)
    length = np.sum(np.hypot(diff[:, 0], diff[:, 1]))
    step = length / (n - 1)
    current_length = 0
    for i in range(len(s) - 1):
        segment_length = np.hypot(s[i + 1, 0] - s[i, 0], s[i + 1, 1] - s[i, 1])

        while current_length < segment_length and len(resampled_s) < n:
            t = current_length / segment_length
            x = s[i, 0] * (1 - t) + s[i + 1, 0] * t
            y = s[i, 1] * (1 - t) + s[i + 1, 1] * t
            resampled_s = np.vstack((resampled_s, [x, y]))
            current_length += step

        current_length -= segment_length

    if len(resampled_s) < n:
        resampled_s = np.vstack((resampled_s, s[-1]))

    return resampled_s


def resample_segments(segments, n):
    return [resample_segment(s, n) for s in segments]
