机器学习踩过的坑

机器学习踩过的坑 封面图

OpenCV读取TIFF数据通道错误

表现为即使设置了imread的flag为IMREAD_UNCHANGED，OpenCV读取后只有一个通道或者通道数不对应；更换Pillow后报错

PIL.UnidentifiedImageError: cannot identify image file

这时候使用Pillow的TIFF插件开启Debug

from PIL import TiffImagePlugin
TiffImagePlugin.DEBUG = True
with open(image_path, 'rb') as f:
    TiffImagePlugin.TiffImageFile(f)

会发现报错

Traceback (most recent call last):
  File ".venv\Lib\site-packages\PIL\TiffImagePlugin.py", line 1409, in _setup
    self._mode, rawmode = OPEN_INFO[key]
                          ~~~~~~~~~^^^^^
KeyError: (b'II', 1, (1,), 1, (16, 16, 16, 16), (0, 0, 0))

然而如果将TIF文件用ENVI打开却可以正常浏览，通道数也正确。 接下来查看Pillow源码 中给出的可接受范围

TIFF数据处理代码
 OPEN_INFO = {
     # (ByteOrder, PhotoInterpretation, SampleFormat, FillOrder, BitsPerSample,
     #  ExtraSamples) => mode, rawmode
     (II, 0, (1,), 1, (1,), ()): ("1", "1;I"),
     (MM, 0, (1,), 1, (1,), ()): ("1", "1;I"),
     (II, 0, (1,), 2, (1,), ()): ("1", "1;IR"),
     (MM, 0, (1,), 2, (1,), ()): ("1", "1;IR"),
     (II, 1, (1,), 1, (1,), ()): ("1", "1"),
     (MM, 1, (1,), 1, (1,), ()): ("1", "1"),
     (II, 1, (1,), 2, (1,), ()): ("1", "1;R"),
     (MM, 1, (1,), 2, (1,), ()): ("1", "1;R"),
     (II, 0, (1,), 1, (2,), ()): ("L", "L;2I"),
     (MM, 0, (1,), 1, (2,), ()): ("L", "L;2I"),
     (II, 0, (1,), 2, (2,), ()): ("L", "L;2IR"),
     (MM, 0, (1,), 2, (2,), ()): ("L", "L;2IR"),
     (II, 1, (1,), 1, (2,), ()): ("L", "L;2"),
     (MM, 1, (1,), 1, (2,), ()): ("L", "L;2"),
     (II, 1, (1,), 2, (2,), ()): ("L", "L;2R"),
     (MM, 1, (1,), 2, (2,), ()): ("L", "L;2R"),
     (II, 0, (1,), 1, (4,), ()): ("L", "L;4I"),
     (MM, 0, (1,), 1, (4,), ()): ("L", "L;4I"),
     (II, 0, (1,), 2, (4,), ()): ("L", "L;4IR"),
     (MM, 0, (1,), 2, (4,), ()): ("L", "L;4IR"),
     (II, 1, (1,), 1, (4,), ()): ("L", "L;4"),
     (MM, 1, (1,), 1, (4,), ()): ("L", "L;4"),
     (II, 1, (1,), 2, (4,), ()): ("L", "L;4R"),
     (MM, 1, (1,), 2, (4,), ()): ("L", "L;4R"),
     (II, 0, (1,), 1, (8,), ()): ("L", "L;I"),
     (MM, 0, (1,), 1, (8,), ()): ("L", "L;I"),
     (II, 0, (1,), 2, (8,), ()): ("L", "L;IR"),
     (MM, 0, (1,), 2, (8,), ()): ("L", "L;IR"),
     (II, 1, (1,), 1, (8,), ()): ("L", "L"),
     (MM, 1, (1,), 1, (8,), ()): ("L", "L"),
     (II, 1, (1,), 2, (8,), ()): ("L", "L;R"),
     (MM, 1, (1,), 2, (8,), ()): ("L", "L;R"),
     (II, 1, (1,), 1, (12,), ()): ("I;16", "I;12"),
     (II, 0, (1,), 1, (16,), ()): ("I;16", "I;16"),
     (II, 1, (1,), 1, (16,), ()): ("I;16", "I;16"),
     (MM, 1, (1,), 1, (16,), ()): ("I;16B", "I;16B"),
     (II, 1, (1,), 2, (16,), ()): ("I;16", "I;16R"),
     (II, 1, (2,), 1, (16,), ()): ("I", "I;16S"),
     (MM, 1, (2,), 1, (16,), ()): ("I", "I;16BS"),
     (II, 0, (3,), 1, (32,), ()): ("F", "F;32F"),
     (MM, 0, (3,), 1, (32,), ()): ("F", "F;32BF"),
     (II, 1, (1,), 1, (32,), ()): ("I", "I;32N"),
     (II, 1, (2,), 1, (32,), ()): ("I", "I;32S"),
     (MM, 1, (2,), 1, (32,), ()): ("I", "I;32BS"),
     (II, 1, (3,), 1, (32,), ()): ("F", "F;32F"),
     (MM, 1, (3,), 1, (32,), ()): ("F", "F;32BF"),
     (II, 1, (1,), 1, (8, 8), (2,)): ("LA", "LA"),
     (MM, 1, (1,), 1, (8, 8), (2,)): ("LA", "LA"),
     (II, 2, (1,), 1, (8, 8, 8), ()): ("RGB", "RGB"),
     (MM, 2, (1,), 1, (8, 8, 8), ()): ("RGB", "RGB"),
     (II, 2, (1,), 2, (8, 8, 8), ()): ("RGB", "RGB;R"),
     (MM, 2, (1,), 2, (8, 8, 8), ()): ("RGB", "RGB;R"),
     (II, 2, (1,), 1, (8, 8, 8, 8), ()): ("RGBA", "RGBA"),  # missing ExtraSamples
     (MM, 2, (1,), 1, (8, 8, 8, 8), ()): ("RGBA", "RGBA"),  # missing ExtraSamples
     (II, 2, (1,), 1, (8, 8, 8, 8), (0,)): ("RGBX", "RGBX"),
     (MM, 2, (1,), 1, (8, 8, 8, 8), (0,)): ("RGBX", "RGBX"),
     (II, 2, (1,), 1, (8, 8, 8, 8, 8), (0, 0)): ("RGBX", "RGBXX"),
     (MM, 2, (1,), 1, (8, 8, 8, 8, 8), (0, 0)): ("RGBX", "RGBXX"),
     (II, 2, (1,), 1, (8, 8, 8, 8, 8, 8), (0, 0, 0)): ("RGBX", "RGBXXX"),
     (MM, 2, (1,), 1, (8, 8, 8, 8, 8, 8), (0, 0, 0)): ("RGBX", "RGBXXX"),
     (II, 2, (1,), 1, (8, 8, 8, 8), (1,)): ("RGBA", "RGBa"),
     (MM, 2, (1,), 1, (8, 8, 8, 8), (1,)): ("RGBA", "RGBa"),
     (II, 2, (1,), 1, (8, 8, 8, 8, 8), (1, 0)): ("RGBA", "RGBaX"),
     (MM, 2, (1,), 1, (8, 8, 8, 8, 8), (1, 0)): ("RGBA", "RGBaX"),
     (II, 2, (1,), 1, (8, 8, 8, 8, 8, 8), (1, 0, 0)): ("RGBA", "RGBaXX"),
     (MM, 2, (1,), 1, (8, 8, 8, 8, 8, 8), (1, 0, 0)): ("RGBA", "RGBaXX"),
     (II, 2, (1,), 1, (8, 8, 8, 8), (2,)): ("RGBA", "RGBA"),
     (MM, 2, (1,), 1, (8, 8, 8, 8), (2,)): ("RGBA", "RGBA"),
     (II, 2, (1,), 1, (8, 8, 8, 8, 8), (2, 0)): ("RGBA", "RGBAX"),
     (MM, 2, (1,), 1, (8, 8, 8, 8, 8), (2, 0)): ("RGBA", "RGBAX"),
     (II, 2, (1,), 1, (8, 8, 8, 8, 8, 8), (2, 0, 0)): ("RGBA", "RGBAXX"),
     (MM, 2, (1,), 1, (8, 8, 8, 8, 8, 8), (2, 0, 0)): ("RGBA", "RGBAXX"),
     (II, 2, (1,), 1, (8, 8, 8, 8), (999,)): ("RGBA", "RGBA"),  # Corel Draw 10
     (MM, 2, (1,), 1, (8, 8, 8, 8), (999,)): ("RGBA", "RGBA"),  # Corel Draw 10
     (II, 2, (1,), 1, (16, 16, 16), ()): ("RGB", "RGB;16L"),
     (MM, 2, (1,), 1, (16, 16, 16), ()): ("RGB", "RGB;16B"),
     (II, 2, (1,), 1, (16, 16, 16, 16), ()): ("RGBA", "RGBA;16L"),
     (MM, 2, (1,), 1, (16, 16, 16, 16), ()): ("RGBA", "RGBA;16B"),
     (II, 2, (1,), 1, (16, 16, 16, 16), (0,)): ("RGBX", "RGBX;16L"),
     (MM, 2, (1,), 1, (16, 16, 16, 16), (0,)): ("RGBX", "RGBX;16B"),
     (II, 2, (1,), 1, (16, 16, 16, 16), (1,)): ("RGBA", "RGBa;16L"),
     (MM, 2, (1,), 1, (16, 16, 16, 16), (1,)): ("RGBA", "RGBa;16B"),
     (II, 2, (1,), 1, (16, 16, 16, 16), (2,)): ("RGBA", "RGBA;16L"),
     (MM, 2, (1,), 1, (16, 16, 16, 16), (2,)): ("RGBA", "RGBA;16B"),
     (II, 3, (1,), 1, (1,), ()): ("P", "P;1"),
     (MM, 3, (1,), 1, (1,), ()): ("P", "P;1"),
     (II, 3, (1,), 2, (1,), ()): ("P", "P;1R"),
     (MM, 3, (1,), 2, (1,), ()): ("P", "P;1R"),
     (II, 3, (1,), 1, (2,), ()): ("P", "P;2"),
     (MM, 3, (1,), 1, (2,), ()): ("P", "P;2"),
     (II, 3, (1,), 2, (2,), ()): ("P", "P;2R"),
     (MM, 3, (1,), 2, (2,), ()): ("P", "P;2R"),
     (II, 3, (1,), 1, (4,), ()): ("P", "P;4"),
     (MM, 3, (1,), 1, (4,), ()): ("P", "P;4"),
     (II, 3, (1,), 2, (4,), ()): ("P", "P;4R"),
     (MM, 3, (1,), 2, (4,), ()): ("P", "P;4R"),
     (II, 3, (1,), 1, (8,), ()): ("P", "P"),
     (MM, 3, (1,), 1, (8,), ()): ("P", "P"),
     (II, 3, (1,), 1, (8, 8), (2,)): ("PA", "PA"),
     (MM, 3, (1,), 1, (8, 8), (2,)): ("PA", "PA"),
     (II, 3, (1,), 2, (8,), ()): ("P", "P;R"),
     (MM, 3, (1,), 2, (8,), ()): ("P", "P;R"),
     (II, 5, (1,), 1, (8, 8, 8, 8), ()): ("CMYK", "CMYK"),
     (MM, 5, (1,), 1, (8, 8, 8, 8), ()): ("CMYK", "CMYK"),
     (II, 5, (1,), 1, (8, 8, 8, 8, 8), (0,)): ("CMYK", "CMYKX"),
     (MM, 5, (1,), 1, (8, 8, 8, 8, 8), (0,)): ("CMYK", "CMYKX"),
     (II, 5, (1,), 1, (8, 8, 8, 8, 8, 8), (0, 0)): ("CMYK", "CMYKXX"),
     (MM, 5, (1,), 1, (8, 8, 8, 8, 8, 8), (0, 0)): ("CMYK", "CMYKXX"),
     (II, 5, (1,), 1, (16, 16, 16, 16), ()): ("CMYK", "CMYK;16L"),
     # JPEG compressed images handled by LibTiff and auto-converted to RGBX
     # Minimal Baseline TIFF requires YCbCr images to have 3 SamplesPerPixel
     (II, 6, (1,), 1, (8, 8, 8), ()): ("RGB", "RGBX"),
     (MM, 6, (1,), 1, (8, 8, 8), ()): ("RGB", "RGBX"),
     (II, 8, (1,), 1, (8, 8, 8), ()): ("LAB", "LAB"),
     (MM, 8, (1,), 1, (8, 8, 8), ()): ("LAB", "LAB"),
 }
可以发现对应不上，所以需要手动设置，查看第二列对应的数据应该为`Photometric Interpretation`，用`tiffinfo`查看
tiffinfo输出
=== TIFF directory 0 ===
TIFF Directory at offset 0x10 (16)
  Image Width: 36382 Image Length: 36951
  Bits/Sample: 16
  Sample Format: unsigned integer
  Compression Scheme: None
  Photometric Interpretation: min-is-black
  Extra Samples: 3<unspecified, unspecified, unspecified>
  Samples/Pixel: 4
  Rows/Strip: 1
  Planar Configuration: single image plane
  Tag 33550: 2.000000,2.000000,0.000000
  Tag 33922: 0.000000,0.000000,0.000000,1129800.409673,4203018.573073,0.000000
  Tag 34735: 1,1,0,7,1024,0,1,1,1025,0,1,1,1026,34737,22,0,2049,34737,7,22,2054,0,1,9102,3072,0,1,32649,3076,0,1,9001
  Tag 34737: WGS 84 / UTM zone 49N|WGS 84|
  GDAL Metadata: <GDALMetadata>
  <Item name="DataType">Generic</Item>
</GDALMetadata>

  GDAL NoDataValue: 65535
接着手动设置对应的Tag，`Photometric Interpretation`对应的为262 ```shell tiffset -d $page-number -s 262 2 input.tif ``` 之后还要对齐最后的`ExtraSamples` ```shell tiffset -d $page-number -s 338 1 2 input.tif ``` 然后Pillow和OpenCV就可以正常读取了
